Type of construction | suspended |
Working width | 1800 mm |
Working width optional | 3000 mm |
adjustable row width | stepless |
Number of max. chopping units (1800 mm) | 8 |
Number of max. chopping units (3000 mm) | 12 |
Power supply | 12, 24, 48 V |
Rear axle | rigid |
Front axle | Swing axle, hydraulically damped |
Type of construction | Telescopic quick release axle |
Adjustment range | 1350, 1500, 1800, 2000, 2250 mm |
Number of traction motor per axle | 2 |
Empty weight without attachment | 900 kg |
permissible total weight | 1600 kg |
Mass of attachment | 600 kg |
Total mass with attachment (3 rows; 50 cm row spacing) | 1300 kg |
Width with bumper min. | 2700 mm |
Width with bumper max. | 3600 mm |
Fuel tank | 30 l |
Gearbox type | Planetary gear |
Clutch | switchable claw clutch |
no oil hydraulics | - |
Maximum power traction drives electr. | 18 kW |
Continuous power electr. S1 | 6 kW |
Gear ratio i | 163.5 |
maximum torque electr. | 8104.7 Nm |
Type | Brushless E-motor |
Number of traction motors | 4 |
rated power generator | 3.9 kW |
rated speed | 3000 1 / min |
Displacement | 0.27 l |
Generator type | 4-stroke gasoline engine with integrated alternator |
Battery capacity | 5 kWh |
Battery voltage | 48 V |
Driving speed | 0.7 m / s |
Machining speed | 0.3 m / s |
Type of construction | Three-point suspension |
Category | I / I |
Type of construction | Ackerman steering with linear motor |
Number of steered axles | 2 |
max. steering angle | 40 ° |
Front tire | 8.3-20 |
Rear tire | 8.3-20 |
Wheelbase (3 rows; 500 mm row spacing) | 3109 mm |
Length (3 rows; 500 mm row spacing) | 4535 mm |
Width without bumper (3 rows; 500 mm row spacing) | 1900 mm |
Height (3 rows; 500 mm row spacing) | 1683 mm |
Power supply | 12, 24, 48 V |
Number of fixed surveillance cameras | 2 |
Number of swiveling surveillance cameras | 1 |
Adjustment range robot length | -150, -300, -450, -600 mm |
